  5pcs StepStick TMC2100 Stepper Motor Driver Ultra-silent Excellent Stability Protection Superior Performance 3D Printer Part Features: 1. High quality and Ultra-quiet. TMC2100 module adopts German imported chips. On the...
  5pcs StepStick TMC2100 Stepper Motor Driver Ultra-silent Excellent Stability Protection Superior Performance 3D Printer Part Features: 1. High quality and Ultra-quiet. TMC2100 module adopts German imported chips. On the...

FREE
SHIPPING

100% MONEY
BACK GUARANTEE

ONLINE
SUPPORT 24/7

FREE
SHIPPING

100% MONEY
BACK GUARANTEE

ONLINE
SUPPORT 24/7

Availability: 549 In Stock

5pcs StepStick TMC2100 Stepper Motor Driver Ultra-silent Excellent Stability Protection Superior Performance 3D Printer Part
01
Features:
1. High quality and Ultra-quiet. TMC2100 module adopts German imported chips. On the other hand, the price is much higher than other stepper drivers. But it still a very good choice for those users who have high requirement for the printer.
2. The working temperature is high. Without fan, the working temperature is about 70 degree in 0.5A, and more than 150 degree in 1A, which may cause losing step. Recommend to do a good job of cooling, the best work current is 0.5A.


Algorithm and Adjustment of TMC 2100 Module Driving Current------And the NOTES!
1. The drive current algorithm: i = vref * 1.9 / 2.5, the default Verf is about 0.65V, so the default current is 0.5A, and the maximum current 1A.
2. Verf measures the voltage of Gnd and potentiometer middle.
3. Please DO NOT connect the motors when measuring the voltage, or it's easy to burn the drive.
4. Please connect the power supply when measuring voltage as well, do not connect only the USB power.
5. Please pay special attention to the direction, do not insert wrongly!!!

Use of the TMC2100 drive module
1. When use in the Ramps1.4 or Gen, or Lerdge touch screen motherboard, please remove the 3 jumper cap under the socket.
2. Please pay attention to direction.
3. The heat sink directly attached to the PCB.
4. The motor direction is opposite to that of A4988 and DRV8825, please adjust the firmware or adjust the motor wiring if you want to change to 4988. And if you use the Lerdge motherboard, please set the direction directly in the setting page of direction of the motor.

Using the TMC2100 driver module on the Lerdge motherboard:

Please remove the 3 jumper cap under the socket when use on Lerdge board. No segment settings in the module. The step value is calculated according to 16 segments, and the internal algorithm uses the differential algorithm to expand the 16 segments to 256 segments.

 note:
every body have the only screwdriver,if you order more and need more screwdriver,pls contact us.   if not,we will only send out one.
