$46.07
FYSETC Spider V2.2 3d Printer Motherboard Tmc2209 32Bit 3D Motherboard Vs Octopus Replace 3D Printer parts for Voron 2.4 Trident Board with 2209x8pcs:including spider board and 8*2209 drivers SET1:including spider...

FREE
SHIPPING

100% MONEY
BACK GUARANTEE

ONLINE
SUPPORT 24/7

Availability: 53 In Stock

FYSETC Spider V2.2 3d Printer Motherboard Tmc2209 32Bit 3D Motherboard Vs Octopus Replace 3D Printer parts for Voron 2.4 Trident

Board with 2209x8pcs:including spider board and 8*2209 drivers

SET1:including spider +8*2209drivers+LCD display B

SET2:including spider +8*2209drivers+LCD display A

Board with 2208x8pcs:including spider and 8*2208 drivers

Board with 6609x8pcs:including spider and 8*6609 drivers

Features

- Compact size: 155.3mm x 76.5mm
- Based on STM32F446 180Mhz,all IOs can withstand 5V voltage
- 8 TMC stepper drivers support, with Uart&SPI support
- Improved TMC jumper settings again,simpler and easier
- 28V input max,12V@5A DC-DC,5V@8A DC-DC (Especially for Raspberry Pi),3.3V@0.8A LDO
- Two car fuses for hot bed input and main power input
- Limit switch socket 24V/5V/3.3V optional, ready for more other equipment, such as -inductive sensor, BL-Touch
- XH2.54 connectors
- 10x PWM capable power mosfet outputs (1 for HotBed, 3 for Heat-End, 3 for fans, 3 for RGB LED strip)
- 3pin temperature header, you can use thermistor or thermocouple (requires AD597 module)
- Up to 8 ways PWM fans (only use 1 extrueder and no 12V/24V RGB used ),2 ways RGB led(12V & 24V optional) ,1 way 5V-RGB led (NEO-PIXEL/WS2812)
- RepRapDiscount SmartController compatible pin header on board
- UART1-Raspberry Pi pin header (including 5V@8A power supply)
- 2X4 PinHeader Out for SD Card moudle
- Onboard micro-SD card
- Type-C and Type-B USB connector optional
- EXP1 & EXP2 have more multiplexing functions, such as USART, I2C, CAN
- SD card & USB upload support
